PAL Type Connector Straight Male Solder Type for Cable
Elecbee Part No:?EB-003-0094Description:? PAL?Type Connector,Male/Plug,Straight/180~,Solder Type,Coaxial CableFree Shipping on Order over $100
Mall price
cut price
Market value
Cumulative evaluation0
Cumulative Sales0
Mobile phone purchase
Product QR Code
Distribut
Dong Wan city to
service
from BEEelec Official Store Delivery and after-sales service
Integral available
Available 0
Number
Inventory  个
Tips

·Does not support return and exchange services

  • Commodity details
  • User comments(0
  • User discussion circle
Mobile phone purchase
Product QR Code
Add to Cart
Price:
Number:
Inventory  个

Commodity details

Product name:PAL Type Connector Straight Male Solder Type for Cable
product number:EB-018-0005
Shop:BEEelec Official Store
weight:0gram
Shelf time:2020-12-25 17:35:26

product

Product features:

  • PAL?Type Connector,Male/Plug,Straight/180~,Solder Type,Coaxial Cable
  • Compact Design for less installation space required;
  • Easy quick connect and disconnect coupling;
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality with much better price.

Appliance:?

  • Consumer Electronic: Statellite Boxes, set top boxes
  • Telecommunications: CATV, CATV Networks.



width=2215

Electrical Characteristics

  • Impedanceㄩ75 ohm
  • Frequency Range: 0~3Ghz
  • VSWR: Straight type 汨 1.2max / R/A type 汨 1.3max
  • Withstanding Voltage: 500 V rms
  • Working Voltage: 170 V rms
  • Center Contact Resistance 汨 10 m次
  • Outer Contact Resistance 汨 5 m次
  • Insultation Resistance 沖 1000 m次
  • RF Leakage -100dB min @1GHz

Mechanical Characteristics

  • Coupling: 3/8-32 thread
  • Cable Retention: 20 lbs min.
  • Durability(mating) 沖 500 cycles

Environmental Characteristics

  • Temprature Range: -40~C ~ +60~C

Material:

PartMaterialFinish
BodyZINC NI:80-120uNI:80-120u
Center Contact Pinphosphor??SN
InsulatorPPWhite
